Introducing the DM-50D easy-to-use 5-inch desktop monitor system

by | Nov 3, 2021 | Featured | 0 comments

Set the Scene: Introducing the DM-50D easy-to-use 5-inch desktop monitor system

High-quality powerful sound that’s perfect for DJing and making music at home

AlphaTheta Corporation has today announced the latest model in the range of desktop monitor systems from its Pioneer DJ brand: the 5-inch DM-50D. The new speaker design combines key elements from the popular DM-40 unit with brand-new components and features to create a more powerful and higher quality sound. Sold in black or white pairs, the speakers are easy to set up, tune, and use – making them ideal for a variety of purposes. Whether you want to play DJ sets or make your own music at home, or regularly switch between the two, the DM-50D system offers the perfect sound.

The DM-50D speakers deliver a balanced, punchy bass sound and they can pump out extra power when you need it as they’re loaded with a new Class D amplifier and a 5-inch woofer in each unit. High frequencies are clearer too, thanks to the advanced new design of the DECO convex diffusers. Want to make some tracks to drop into your next DJ set? Simply flick the switch on the speaker to change from DJ mode to Production mode and the DSP settings will automatically adjust to create the best sound for each application.

You can connect your DJ setup or home studio to the RCA, mini jack, and newly added TRS input terminals on the DM-50D speakers. Even better, the volume knob and headphones socket are on the front panel for quick connection and level control. And, with the choice of black or white models, you can pick the color that best suits the setting in your home.

Advanced design for higher quality sound

Each DM-50D speaker produces pure, balanced bass sound, thanks to a new Class D amplifier with 96 kHz sampling DSP. Another advancement from the DM-40 model comes in the updated design of the DECO convex diffusers which help deliver crystal-clear high frequencies in every direction, so you can enjoy a wide sweet spot and 3D stereo sound wherever you are in the room. When you need to turn up the volume, the new 5-inch woofer creates extra power and it’s perfectly aligned with the tweeter so you’ll hear all sound frequencies clearly. The grooves on the ducts reduce air friction so that bass is tight and punchy, even if you position the speakers against a wall. Plus, the curved front edges provide maximum rigidity and minimum resonance for clean audio at any volume level.

DM-50D Advanced design

2-way sound mode optimized for DJing and music production

There’s no need to decide whether you want a set of monitors that are best for DJing or making music, because the DM-50D speakers are perfect for both. Just flip the switch to choose either DJ mode or Production mode and the DSP settings will be optimized for the task, leaving you free to concentrate on your mix.

DM-50D 2-way sound mode

Easy to use with different DJ or production equipment

With RCA, mini jack, and the newly added TRS input terminals, you can connect different kinds of gear such as DJ controllers and mixers, or the laptop or soundcard you use for producing your own music. Connecting and disconnecting your headphones is simple via the socket on the front panel of the DM-50D. There’s no need to reach around the back of the speakers to adjust the volume either, as the level knob is also right in front of you.

DM-50D Easy to use

Smart design, available in 2 colors

Bring a slick, professional look to your setup by choosing from 2 different colors. The finish of the black DM-50D matches perfectly with classic DJ gear while the white DM-50D-W might better complement the interior design of your home.

DM-50D specifications

Type 2-way bass reflex, active monitor speakers
Amplifier type Class D with DSP
Amplifier Output
  • Lch: 25 W / 4 Ω
  • Rch: 25 W / 4 Ω
Input terminals (balanced input) 1/4” TRS jack x 1
Input terminals (unbalanced input) RCA pin jack x 1, 3.5-mm stereo mini jack x 1
Input impedance 10 kΩ
Output terminal 3.5-mm stereo mini jack x 1
Enclosure Bass reflex
Enclosure material MDF vinyl laminate
Woofer (LF driver) 5″ (127 mm) fiberglass cones
Tweeter (HF driver) 3/4” (19 mm) soft dome
Supported voltages AC 110 V — 240 V, 50 Hz / 60 Hz
Power consumption 25 W
Power consumption during standby mode 0.3 W or less
Max dimensions (W x D x H) Lch: 175 x 262 x 257 mm / 6.89” x 10.32” x 10.12”
Rch: 175 x 262 x 247 mm / 6.89” x 10.32” x 9.72”
Weight Lch: 3.9 kg / 8.6 lbs.
Rch: 3.5 kg / 7.7 lbs.
Accessories
  • Power cord
  • Audio converter cable (3.5 mm stereo mini plug to RCA)
  • Speaker cord
  • Bottom cushion
  • Quick Start Guide
  • Precautions for Use
  • Warranty

* Disclaimer: Specifications and price are subject to change.
* Other product, technology, and company names, etc. mentioned herein are trademarks or registered trademarks of their respective owners.
